Spring Energized PTW Seal

The Spring Energized PTW Seal works by a spring-loaded seal that consists of a polymeric seal and a corrosion-resistant stainless steel spring. The sealing ring is installed in the groove, the spring is pressed to form an outward tension, and the sealing lip is pressed against the sealing groove. Since the spring permanently provides the elastic force to the sealing lip, it can compensate for the wear of the sealing shell and the eccentricity of the fitting part, thereby forming Sealing from vacuum to low pressure....

Send Inquiry

Product Description

Spring Energized PTW Seal is rod seal and used for Flanged heel groove.

The U-shaped flanged PTFE sealing ring is equipped with a one-way seal for the shaft of the special O-shaped spiral stainless steel spring. This seal can be applied to various working conditions as well as to certain special media requirements.

Spring Energized PTW Seal
.jpg

Name	Spring Energized PTW Seal
Sliding speed[m/s]	15
Temperature [° C]	-40...+260
Pressure Pr:N/mm²	45（max）
Medium	Virtually all fluids, chemicals and gases
Material	Virgin PTFE, PTFE+carbon, PTFE+glass fiber, PTFE+bronze, PTFE+polyester, PEEK etc. Other special material is also available.
Color	coffee, white, black, blue, beige
Type of spring	V-spring, Helical Spring, Slanted Coil Spring
Size	Supply standard and non-standard size
Characteristics	Rotary plug has a flange, it prevents the seal in the groove rotation, it has a short and explained dynamic lip, to reduce friction, so that seals even in the high viscosity of the medium life long and have a good wiping ability.
Advantage	- Good scraping effect - No creep when precise control - Good abrasion resistance and dimensional stability - adapts to rapid temperature changes - No pollution to food, liquids, etc. - Can be disinfect - Unlimited storage period
Certificates	ISO9001-2008, SGS
Delivery time	5 to 7 working days, 2 days for in stock
MOQ	20
